Melamine Resin Panel Cleanroom Doors

The melamine resin panel clean door can be equipped with a glass observation window, a door closer installed at a suitable location, and an automatic lifting seal strip at the bottom. It comes with high-quality hardware accessories such as a door closer, lock, observation window, and a lifting threshold.


Product Parameters

1. The melamine resin panel clean door can be equipped with a glass observation window, a door closer installed at a suitable location, and an automatic lifting seal strip at the bottom. It comes with high-quality hardware accessories such as a door closer, lock, observation window, and a lifting threshold.
2. The door frame and door leaf are made from high-strength aluminum alloy with cut and spliced corners. The door leaf surface is composed of melamine resin board, which is resistant to bacteria and wear, capable of withstanding frequent disinfection treatments in pharmaceutical factories. It is non-porous, dust-free, and easy to clean.
3. The observation window features a double-layer hollow design, with the edges of the window requiring a flange treatment. The internal cavity of the window is equipped with a desiccant to ensure no fogging occurs. The 5mm thick tempered glass is surrounded by a 20mm black edge, with the glass surface flush with the door panel, resulting in an aesthetically pleasing and transparent appearance.
4. The lock body is made of stainless steel with a handle that does not have any exposed fixing screws.
5. A third-party fire resistance test report for the door is provided, with a fire resistance time of not less than 1 hour.
6. The door panel is equipped with an auto-applied self-foaming polyurethane seal strip from a built-in adhesive applicator, ensuring it does not fall off and maintaining the door's sealing performance. The bottom of the door panel features an adjustable aluminum silicone seal strip.
7. The door meets the relevant standards and requirements of the clean industry.

serial number

name

Specification

Remark

1

Door frame/door panel edging

Aluminum alloy

Surface treatment, optional silver oxidation, sand electro-white, plastic spraying

2

door panel

Melamine resin plate/color steel plate

Yuanda standard configuration

3

Locks

Stainless steel handle lock

Yuanda standard configuration, three-year warranty

4

window glass

5mm thick tempered

Lined with 304 stainless steel liner, specification 386*586 R101

5

door closer

Non-positioning (nickel plated)

Yuanda standard configuration, optional positioning/non-positioning

6

Hinge (Hinge)

304 stainless steel

Yuanda comes standard with 1 door leaf and three hinges

7

Lifting sweeping strip

Aluminum alloy silicone leather strip

Good elasticity and permanent

8

sealing strip

Silica gel

Anti-aging for 10 years

9

paper honeycomb

Melamine resin board: 41.5mm thick

Color steel plate: 48.5mm thick

Flame retardancy: optional aluminum honeycomb, rock wool

10

glass glue

Silica gel

Yuanda standard configuration

11

High-temperature resistant glue

Polyether, polyisocyanate

Can withstand high temperatures up to 300 degrees

12

Mounting screws

Self-tapping screws

Installed

13

Color (galvanized sheet)

Polyester resin plastic powder

The color is outdoor pink, it will not discolor for 10 years outdoors, it can be antistatic, VHP, and antibacterial

Suzhou Yuanda Purification is famous Melamine Resin Panel Cleanroom Doors Manufacturer and supplier in China, we have a high-level R&D team with over 20 years of experience in clean door and window design and development.
